ONBOARD COMPUTER WITH GNSS

Command & Control
Cad file & datasheet
Select Options
Select Options
flight heritage badge state of the art report badge
Cad file & datasheet
Select Options
Select Options
2X
HIGHER RADIATION RESILIENCE
GNSS
INTEGRATED SYSTEM
ADCS
READY SENSORS AND DRIVERS

Flight-proven, efficient and robust computer for your mission

FEATURES
Processor
ARM Cortex M7
Program Memory Size
2 MB
SRAM
1 MB
Card Slot
MicroSD
External FRAM Memory
8 Mbit
Compatibility
Full set of drivers for EnduroSat modules
Double-Redundancy
3-axis magnetometer
Clock Type
Real Time Clock
Power Saving
Flexible frequency
Mass
180 g
Interfaces
4x RS-485, 2x RS-422, 2x UART, 2x I2C, SPI, USB, CAN
GNSS Receiver Type
NovAtel OEM 719
Signal Tracking
from GPS L1, Galileo E1
PPS Signal Error
±0.5 ppm
Position Accuracy
1.5 m
Velocity Accuracy
0.03 m/s
Time Accuracy
20 ns
Onboard Computer with GNSS web render 8
Command & Control

Included

Complete User Manual
USB cable
JTAG and debugging cables (with SDK)
5h engineering support
Delivery cost
Handling and administration costs
Flight-proven, efficient and robust computer for your mission
Onboard Computer with GNSS web 2
Onboard Computer with GNSS web render 7

Integrated GNSS receiver with flight heritage in LEO

Onboard Computer with GNSS web render 1

Reliable data handling and avionics for up-to 5 years in LEO

RADIATION-TESTED AT 40 KRAD TOTAL IONIZING DOSE (TID)
Onboard Computer with GNSS web render 6

ADCS-ready magnetorquer and sensor drivers

Onboard Computer with GNSS web render 9

8 GB secure onboard memory

PRODUCT GALLERY
Onboard Computer with GNSS web 4
Onboard Computer with GNSS web 6
Onboard Computer with GNSS web 11
Onboard Computer with GNSS web 12
Onboard Computer with GNSS web 2
OBC
Onboard Computer (OBC)
Processor
ARM Cortex M7
Program Memory Size
2 MB
SRAM
1 MB
Discover
2500
MODULES IN ORBIT
50
DELIVERED SATELLITES
200
TB DATA DOWNLINKED
All our products undergo Space Qualification, involving stringent testing under extreme conditions to ensure their robustness and high performance
LEARN MORE

Datasheet & CAD File

Onboard Computer With GNSS
