Reliable TMTC

S-Band Transceiver I

High efficiency full-duplex S-band Transceiver

S-Band-Transceiver-I-cubesat-communication-module-endurosat

High efficiency full-duplex S-band Transceiver

HIGHefficiency
FULLduplex
AX.25protocol capable

Secure system for Telemetry and Telecommands (TMTC) and in-orbit updates applications

S-Band-Transceiver-I-cubesat-communication-module-endurosat

Next level of security based on the Advanced Encryption Standard (AES)-128/256

S-Band-Transceiver-I-cubesat-communication-module-endurosat

Applications

Intersatellite communications iconInter-satellite Communications
Telecommand uplink (TC) iconTelecommand Uplink (TC)
Satellite software updates iconIn-orbit Updates

Industrial, Scientific and Medical (ISM) or Commercial Bands

S-Band-Transceiver-I-cubesat-communication-module-endurosat

Features

Frequency range (Tx) 2200 to 2290 MHz (commercial) or 2400 to 2450 MHz (ISM)
Frequency range (Rx) 2025-2110 MHz (commercial) or 2400-2450 MHz (ISM)
Modulation FSK/MSK/GFSK/GMSK
Configurable Data Rate 0.1-125 kbps
Mass < 200 g
Firmware updates Local and remote (in-flight) secured application update
Tx Power 20-30 dBm configurable
Antenna Connectors SMP for Rx and Tx
Wide Power Supply Range 5-12 V
Interfaces RS-485, CAN, RS-485/422
Easy set-up Dedicated connector for calibration and debugging

In-flight configurable parameters

Features in-orbit firmware update capability

S-Band-Transceiver-I-cubesat-communication-module-endurosat

Included

user manual book icon Complete User Manual
included cables icon Complete set of cables
customer support icon 5h engineering support
delivery cost icon Delivery cost
handling and administration costs icon Handling and administration costs
