CubeSat UHF Transceiver Type 1.2

uhf-communication-cubesat-module-endurosat

CubeSat UHF Transceiver Type 1.2

  • Frequency range: 430-440 MHz;
  • Modulations: GFSK, 4FSK, GMSK, OOK;
  • Protocol: AX.25;
  • Maximum Tx power: 1.5 W;
  • Power amplifier efficiency: >70%;
  • Power Supply: 3.2 – 3.4 V;
  • Typical Tx current consumption: up to 800 mA;
  • Frequency stability: +/- 2.5 ppm;
  • Data rate in the air: up to 100 kbps;
  • Sensitivity: -113 to -121 dBm;
  • Interfaces: UART / I2C / CAN / RS485 / USB;
  • Type: Half-duplex;

Included with UHF Transceiver Type 1.2

Package

Metal box

Engineering Support

5 hours

Tech and User information

USB Drive

Qualification tests

Space qualification tests are performed on the Qualification Engineering Model. Qualification tests level and duration follow the ESA standard ECSS-E-ST-10-03C and GEVS: GSFC-STD-7000A.

Functional Test
Random Vibration
Sinusoidal Vibration
Pyroshock Test

Thermal Cycling
Thermal Vacuum
Total Ionizing Dose – planned in the coming weeks
